Nickel Plated Copper High Temperature FEP Wire for Robot Industrial Power with 600V Rating

  • Nickel Plated Copper High Temperature FEP Wire for Robot Industrial Power with 600V Rating
  • Nickel Plated Copper High Temperature FEP Wire for Robot Industrial Power with 600V Rating
  • Nickel Plated Copper High Temperature FEP Wire for Robot Industrial Power with 600V Rating
  • Nickel Plated Copper High Temperature FEP Wire for Robot Industrial Power with 600V Rating
  • Nickel Plated Copper High Temperature FEP Wire for Robot Industrial Power with 600V Rating
Herkunftsort Guangdong, China
Markenname MYSUN
Modellnummer CQC20011252316
Min Bestellmenge 3050

Treten Sie mit mir für freie Proben und Kupons in Verbindung.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skypen: sales10@aixton.com

Wenn Sie irgendein Interesse haben, leisten wir 24-stündige Online-Hilfe.

x
Produktdetails
Leitermaterial Kupfer aus Dose Durchmesser 0,051 mm2 bis 16,00 mm2
Isolationsmaterial FEP Nennspannung 600V
Leitertyp Solide Form Runden
Temperaturbewertung 150 °C, 200 °C Maximalleiter Widerstand 381 Ω/KM bis 1,17 Ω/KM
Länge der Einheit 305/1000 M/FT bis 100/328 M/FT Nenndicke 0,510 mm bis 0,760 mm
Isolationsdurchmesser 1,32 mm bis 7,20 mm Konstruktion 7/0,10 bis 133/0,393
Leiterdurchmesser 0,30 mm bis 5,60 mm Nennspannung 600V
Isolierungstyp FEP
Hervorheben

Nickel Plated Copper FEP Wire

,

High Temperature FEP Wire

,

Robot Industrial Power FEP Wire
Hinterlass eine Nachricht
Produkt-Beschreibung
Ez-200/TX/FEP Wire Red 600V 150°C Nickel Plated Copper High Temperature FEP Wire for Robot Industrial Power
Nickel Plated Copper High Temperature FEP Wire for Robot Industrial Power with 600V Rating 0 Nickel Plated Copper High Temperature FEP Wire for Robot Industrial Power with 600V Rating 0
Specification
CQC V048486 E-200/TX/FEP Wire 600V 200°C UL1330 Conductor Insulation Max. Cond Resistance (Ω/KM) Unit length (M)(Ft)
Size (AWG) Construction (No.mm) Diameter (mm) Nominal thickness (mm) Diameter (mm)
0.051 7/0.10 0.30 0.510 1.32 381, 610/2000
0.08 7/0.127 0.38 0.510 1.40 239, 610/2000
0.13 7/0.16 0.48 0.510 1.50 150, 305/1000
0.21 19/0.12 0.60 0.510 1.62 94.2, 305/1000
0.32 19/0.15 0.78 0.510 1.80 59.4, 305/1000
0.40 19/0.17 0.85 0.510 1.90 46.6, 305/1000
0.52 19/0.19 0.96 0.510 2.00 37.4, 305/1000
0.75 19/0.225 1.12 0.510 2.15 24.8, 305/1000
0.82 19/0.235 1.17 0.510 2.20 23.5, 305/1000
1.00 19/0.26 1.35 0.510 2.40 18.7, 305/1000
1.31 19/0.30 1.52 0.510 2.60 14.7, 305/1000
1.50 19/0.32 1.60 0.510 2.85 12.5, 305/1000
2.08 19/0.375 1.89 0.510 2.95 9.22, 305/1000
2.50 19/0.41 2.08 0.510 3.10 7.47, 305/1000
3.31 19/0.475 2.39 0.510 3.45 5.75, 100/328
4.00 19/0.52 2.70 0.510 4.30 4.68, 100/328
5.26 19/0.60 3.00 0.760 4.60 3.62, 100/328
6.00 19/0.64 3.25 0.760 4.80 3.12, 100/328
8.37 68/0.40 3.90 0.760 5.50 2.23, 100/328
10.00 37/0.59 4.30 0.760 5.90 1.87, 100/328
13.30 133/0.36 5.20 0.760 6.80 1.41, 100/328
16.00 133/0.393 5.60 0.760 7.20 1.17, 100/328
Click Contact us Get the Best Quote
Company Profile
Nickel Plated Copper High Temperature FEP Wire for Robot Industrial Power with 600V Rating 2 Nickel Plated Copper High Temperature FEP Wire for Robot Industrial Power with 600V Rating 2 Nickel Plated Copper High Temperature FEP Wire for Robot Industrial Power with 600V Rating 4 Nickel Plated Copper High Temperature FEP Wire for Robot Industrial Power with 600V Rating 4
Our Products
Nickel Plated Copper High Temperature FEP Wire for Robot Industrial Power with 600V Rating 6 Nickel Plated Copper High Temperature FEP Wire for Robot Industrial Power with 600V Rating 6
Application
Nickel Plated Copper High Temperature FEP Wire for Robot Industrial Power with 600V Rating 8 Nickel Plated Copper High Temperature FEP Wire for Robot Industrial Power with 600V Rating 8
Our Overseas Clients
Nickel Plated Copper High Temperature FEP Wire for Robot Industrial Power with 600V Rating 10 Nickel Plated Copper High Temperature FEP Wire for Robot Industrial Power with 600V Rating 10
Exhibition
Nickel Plated Copper High Temperature FEP Wire for Robot Industrial Power with 600V Rating 12 Nickel Plated Copper High Temperature FEP Wire for Robot Industrial Power with 600V Rating 12
Certifications
Nickel Plated Copper High Temperature FEP Wire for Robot Industrial Power with 600V Rating 14 Nickel Plated Copper High Temperature FEP Wire for Robot Industrial Power with 600V Rating 14
FAQ
1. Who Are We?

We are a professional manufacturer of high-temperature wires and cables with 26 years of electric wire experience. Our headquarter is located in Shenzhen, Guangdong, China, and our two production bases are located in Dongguan, Guangdong, China and Jingzhou, Hubei, China.

2. What Can We Provide?

We can provide high-temperature wires and cables, silicone tubing - including silicone rubber wire, XLPE, FEP/PFA/ETFE/PTFE wire, new energy cable, wiring harnesses.

3. Why Choose Us?
  • Free Sample
  • Competitive Price
  • High Quality Standard
  • Customized Service
4. What Certifications Do We Have?

We have UL, cUL, VDE, Reach, CE, ROHS, CCC, CQC Certification.

5. What Services Can We Provide?

Accepted Delivery Terms: FOB, CIF, EXW, FAS, CIP, FCA, DDP, DDU. Accepted Payment Currency: USD, EUR, CNY. Accepted Payment Type: T/T, L/C, PayPal, Western Union, Cash.
